GE IC695CPU310 Central Processing Unit

Specifications (continued)

Serial Ports

• Two 16550-compatible DB-9 serial ports

  • COM1 routed to front panel

  • COM2 routed to P2

• Independent 16-byte FIFO per port

• Baud rates up to 115 Kbaud

PMC Extension Slot

• One 133 MHz PCI-X PMC site

• 46-pin P2 user I/O per VITA35, P4V2-46dz

• Optional expansion: 3 × 32-bit/33 MHz PMC sites with PMC237CM1/V

Programmable Timers

• Two 16-bit timers

• Two 32-bit timers

• Mapped in PCI memory space

• Fully software-programmable with PCI bus interrupt generation

Watchdog Timer

• Programmable intervals

• Supports interrupt and board reset triggers

Nonvolatile SRAM

• 32 KB capacity

Dimensions (6U Eurocard, single slot)

• Height: 9.2 in (233.4 mm)

• Depth: 6.3 in (160 mm)

• Thickness: 0.8 in (20.3 mm)

Power Requirements

• +5 VDC (±5%): typical A, maximum A (value not specified in text)

• +12 VDC (±5%): < 1 mA

• –12 VDC (±5%): < 1 mA

• Note: VME interface allows only –4.875 V

• Note: Power requirements exclude PMC site

Airflow

• Forced-air cooling required

• Minimum: 400 LFM, measured at heatsink outlet

Temperature

• Operating:

  • 0 to +70 °C (Intel Celeron M)

  • 0 to +55 °C (Intel Core 2 Duo)

• Storage: –40 to +80 °C

Altitude

• Operating: 0 to 10,000 ft (3,000 m)

• Storage: 0 to 40,000 ft (12,000 m)

Humidity

• Operating: 5% to 95% RH, non-condensing

• Storage: 5% to 95% RH, non-condensing

MTBF

• Contact factory
